● 4 analog balanced inputs and 4 analog balanced outputs, with a maximum input/output of 17dBu (5.48Vrms) without distortion
● Stereo USB sound card function, supporting playback and recording
● USB/RS232/RS485, Network interface, computer software control and central control function, through the network connection can simultaneously manage multiple devices
● External 8-channel GPIO interface
● LCD screen, supporting configuration of device name/preset/IP, input/output volume, input mode, device version view and other functions
● DSP functions include AFC, AEC, ANC, AGC, AUTO MIX, MATRIX MIX, Noise Gate, PEQ , Delayer, FIR Filter, High and Low Pass Divider, Compressor, Limiter
● Input 15-band PEQ, output 10-band PEQ
● Input/output 2000ms delayer per channel
● Output 512 Tap FIR per channel
● Input each channel voice excitation function (camera tracking), support with PELCO-D, PELCO-P, VISCA protocol, camera control
● 60 preset memory positions
● Support line control box control, Android APP Network Control
● Support archive locking, hide setting parameters, and ensure project technical security
Ordering Code:
DSP-440N2: 4 In 4 out DSP audio processor AFC,AUTOMIX, RS 232 and camera control
DSP-440ND2: 4 In 4 out DSP audio processor AFC,AUTOMIX, RS 232 and camera control, DANTE Ultimo 4 Channel
