FEATURES
● 32-way max. inputs , 4-way stereo. +48V phantom power supply, independent switch control. High-pass filter selector switch
● Preamplifier with high stability and low noise provide the operator with suitable level dB output
● On each way has, high pass filter, insertion points (INSERT), 4 band frequency scan equalizer with switch selection, 4 band LED pass level indicator, direct output (DIRECT)
● Mute and monitor switch are installed on channels of incoming and output signals. Powerful SOLO tracking system for freely monitoring of mixing output, including outputs of stereo, mono, auxiliary, group and record. Headphone monitoring can be selected as mono or stereo. And both headphone and speaker feature separate level control.
● The intercom system can be transmitted to any output group
● Output channels include 2 mixing stereos (Master L and Master R), 2 auxiliary mixer stereos, Master B (can be switched to 2 stereo mixing and sum outputs), 4 group outputs, 4 monitor outputs, and 4 auxiliary outputs. There are 14 band LEDs for each output
● Outside power supply to reduce background noise
