8 In 8 Out DSP Audio Processor
8 In 8 Out DSP Audio Processor
8 In 8 Out DSP Audio Processor
8 In 8 Out DSP Audio Processor
8 In 8 Out DSP Audio Processor

8 In 8 Out DSP Audio Processor

The DSP-880N2/DSP-880ND2/DSP-880ND3 audio processor combines Auto Mixer, Matrix Mixer, and Feedback suppressor in one purpose-built DSP processor. At the same time, it has independent FIR/AFC/ AEC/ ANS/ AGC gain sharing automatic mixing, threshold automatic mixing and other processing modules. The DSP-880N2/DSP-880ND2/DSP-880ND3 includes 8 mic/line analog inputs, 8 analog outputs to meet the needs of a wide range of audio processing applications such as boardroom, medium/large conference rooms, courtrooms, auditoriums and multi-purpose halls.

  • Model:： DSP-880N2
Quote
Close
Enter your details and submit
We'll aim to get back to your with a quote within 24hrs

The DSP-880N2/DSP-880ND2/DSP-880ND3 audio processor combines Auto Mixer, Matrix Mixer, and Feedback suppressor in one purpose-built DSP processor. At the same time, it has independent FIR/AFC/ AEC/ ANS/ AGC gain sharing automatic mixing, threshold automatic mixing and other processing modules. The DSP-880N2/DSP-880ND2/DSP-880ND3 includes 8 mic/line analog inputs, 8 analog outputs to meet the needs of a wide range of audio processing applications such as boardroom, medium/large conference rooms, courtrooms, auditoriums and multi-purpose halls.


● 8-channel analog input and 8-channel analog output, Microphone or Line in switch

● +48V Phantom power per input channel

● AFC in each input

● AUTO-MIX and MATRIX-MIX

● 15 PEQS per input and 10 PEQS per output

● USB free driver connect, RS232/485 connector for center control


Ordering Code:

DSP-880N2: 8 In 8 out DSP audio processor AFC,AUTOMIX, RS 232 and camera control

DSP-880ND2: 8 In 8 out DSP audio processor AFC,AUTOMIX, RS 232 and camera control, DANTE Ultimo 4 Channel

DSP-880ND3: 8 In 8 out DSP audio processor AFC,AUTOMIX, RS 232 and camera control, DANTE 8 Channel



ModelDSP-880N2
Input Channels8 balanced. Mic/line level
Connectors3.81 mm Euro block
Input Impedance11.5KΩ
Maximum Input Level14dBu/Line, -7dBu/Mic
Phantom Power+48VDC, 10mA, selectable per input
Output Channels8/8/16 balanced, line level
Output Impedance150Ω
Frequency Response20Hz-20kHz(+-0.5dB)/Line
20Hz-20kHz(+-1.5dB)/Mic
THD+NLINE: 0.003%
MIC: 0.005%
SNR105dB(@12dBu,1kHz,A-wt)/Line
95dB(@-7dBu,1kHz,A-wt)/Mic
USBMicro-B type, free driver
RS232Serial port communication
TCPIPRJ-45, Optional
LED Status IndicatorsPower, Link, +48V, Input and Output Audio signal
Mains VoltageAC100V---240V 50/60 Hz
Dimensions44mmx483mmx210mm
Net Weight2.8kg
Operating Temperature-20℃-60℃
Cooling System32-bit fixed/floating-point DSP
Signal ProcessorActive, Fan inside
Audio Latency< 1ms
A/D and D/A Converters24-bit
Sample Rate48KHz
