16-Channel Digital Mixing Console with 16 Mic/Line Inputs, 12 Analog Outputs

16 channel TOTAL RECALL digital mixer, equipped with high-end microphone amplifier and 12 mixing buses, and sub-groups can be set
Each input channel has a 5ms delay, high-pass filter, high and low filters, 7-segment parametric equalizers, compressor with sidechain function, noise gate
Each output channel has a 5ms delay, high and low filters, 7-segment parametric equalizers, limiters, noise gate
Built-in effector, external effector can be inserted
Built-in USB sound card, drive free, supports MAC, Windows, IOS, and can be inserted into 15/16 through USB sound card for playing and computer recording
4 group outputs, 4 auxiliary outputs, 1 effect echo input
Support total recall preset storage and recall function, allowing offline saving/recall of 9 scenes
High-end microphone amplifier, 48V phantom power
Each channel has a complete dynamic, EQ and level meter
25 low-noise 100mm electric thrusters
11 analog XLR outputs, 2 monitoring headphone interfaces
Support scene management function, which can save 9 kinds of scenes, making it easy to manage complex scenes
Both input and output have adjustable linear delay
Scene management system suitable for live performance

Model	DMX-1612
Input
THD+N	＜0.006%A-weighted
CMRR, XLR @20dB Gain (Typical)	＞70dB
CMRR, XLR @40dB Gain	＞80dB
Equivalent Input Noise (Input Short Circuit)	-110dBu
Input Compensating Resistance XLR, Unbalanced/Balanced	5kΩ/10kΩ
Output
Frequency Range	10-20kHz
Sampling Rate@48kHz	0dB~-1dB
Dynamic Range Analog In Analog Out (Typical)	106dB
A/D Dynamic Range, pre-putted to the Converter (Typical)	109dB
D/A Dynamic Range, Converter to output	108dB
Channel Crosstalk@1kHz	100dB
Output Level, XLR, NOM/MAX	+4dBu/+21dBu
Output Compensating Resistance XLR, Unbalanced/Balanced	75Ω/75Ω
