Active Portable PA speaker-SPIRIT, professional sound system, loudspeaker, amplifier

2-way active, light-weight and highly efficient professional sound reinforcement speaker system.
The Class D power amplifiers with its total power up to 500W provide tremendous sound pressure and incredible low-frequency impact.
Multiple audio spectrum processing technology brings a melodious sound quality and a live-like musical feeling.
The built-in professional audio compression limiter effectively protects the entire speaker system.
Professional mixer with 2-way microphone input low noise and low distortion.

Model	PAT-12	PAT-15
System	Equipped with EQ, Multi-channel microphone and line input, digital amplifier, active 2-way speaker
Driver Quantity	12"×1(Low)1×Φ25mm Driver	15"×1(Low)1×Φ34mm Driver
Frequency Response(±3dB)	60Hz-18KHz	55Hz-18KHz
Frequency Response(±10dB)	54Hz-20KHz	45Hz-20KHz
Max Sound Level(dB/1M)	103dB	110dB
Max Output Power	300W(Bass)/130W(Tred)	400W(Bass)/180W(Tred)
Level Adjust Range	±15dB(80Hz)-Bass±15dB(12KHz)-Treb	±15dB(80Hz)-Bass±15dB(12KHz)-Treb
Distortion	Line-0.02%, Microphone-0.04%	Line-0.02%, Microphone-0.04%
Load Impedance	Treb-8 Ohm, Bass-8 Ohm	Treb-8 Ohm, Bass-8 Ohm
Input Impedance	Line-14KOhm, Microphone-14K Ohm	Line-14K Ohm, Microphone-14K Ohm
Connectors	XLR;1/4"TRS	XLR;1/4"TRS
Dimensions(H×L×D)	578×345×277mm	713×431×320mm
Net Weight	14kg	19kg

Active Portable PA speaker
